Previous DUOGUARD M2
DUOGUARD M3
Brand: Chubb
Series: Duoguard Series
Protect your valuables and documents from both fire and theft in your office or retail environment: The Chubbsafes DuoGuard is a range of certified safes providing EN 1143-1 T2 burglary protection and EN 1047-1, respectively NT Fire 017 fire resistance. You want a robust but lightweight safe to keep your theft-prone, valuables and documents secure in your office or retail environment. The Chubbsafes DuoGuard offers combined fire and burglary protection certified by ECB•S and SP technical Research Institute of Sweden, two leading accreditation companies. Thanks to new Dualite torch-resistant barrier material, these customisable safes are designed to provide optimal security even at a reduced weight.
Specifications
External Size: H 1150mm X W 600mm X D 561mm
Internal Size: H 1050mm X W 500mm X D 386mm
Weight: 264kg
Fire Proof: 90 mins
Key Features
- Burglary protection in accordance with EN 1143-1, as certified byECB•S for Grade I.
- Ideal safe for protecting cash and valuable items, as well as passports, title deeds and other important documents in the home and office.
- Torch-resistant barrier material – Dualite – ensures burglary and fire protection whilst also reducing its total weight and minimising transportation and installation costs.
- Fitted with an active relocker and anti-drilling plates incorporated into the boltwork to withstand burglary attempts (T200X carbide-clad steel plates).
Fittings
INTERNAL FITTINGS
- Model 115 to 205 comes standard with two pieces of adjustable shelf and three pieces for model 290.
OPTIONAL INTERNAL FITTINGS
- Extendable shelf
- Extensible drawer
- Lockable drawer
- Data media insert
LOCK OPTIONS
DuoGuard safes fitted with a high-security electronic lock (Class B) for model 115-290 as the primary lock. The primary lock can be supplemented by a combination lock or both a key lock and electronic lock can be fitted as an option. All locks are independently tested and are certified in accordance with the EN 1300 standard. DuoGuard’s high-security electronic lock- certified Class B-includes the following features, easily programmed by the owner:
- 1 master code, 1 supervisor code and 8 user codes.
- Time delay of up to 99 minutes between lock being operated and door being opened.
- Opening window between 1-19 minutes.
- Equipped with time delay override.
- Optional function to raise silent alarm if lock is being opened under duress.
FIRE TESTING
DuoGuard has been approved in accordance with the European standard, EN 1047-1 in fire class S 60 P, which means the safe will protect paper documents for one hour. This certification was awarded by ECB.S (European Certification Board Security Systems). To comply with this standard, DuoGuard has been exposed to a constantly heated environment of over 1,000°C, during which temperature is measured and relative air humidity checked.
STAGE 1
The safe is placed in a furnace and heated to a constant temperature of almost 1,000°C for 60 minutes to simulate the effects of a severe fire. Its internal temperature is measured during the heat and must never exceed 170°C, which is the temperature at which paper start to suffer damage.
STAGE 2
The safe is removed from the furnace and cooled. The internal temperature continues to be measured during the subsequent cooling down period. When opened, it must not exceed 150°C.
BURGLARY TESTING
DuoGuard has been approved by ECB-S in accordance with the European EN 1143-1 standard for burglary protection in Grade I. A range of attack tools were used to test DuoGuard’s level of resistance, ranging from basic tools to sophisticated thermal and electrical equipment.
